The quality and performance of AYATER coalescer cartridges can be guaranteed as original elements. In addition, we can guarantee the quality, service life and water absorption of this coalescer.
I-628C5TB Coalescer Cartridges are designed to separate dispersed emulsified water particles and contaminants from aviation fuel. I-628C5TB Coalescer Cartridges are primarily used to coalesce emulsified water and remove particles from hydrocarbon fluids. The most important application is the filtration of aviation paraffins. Glass fiber coalescers combine deep particle filtration with a deep coalescing structure. These models have progressively thinner layers for deep particle filtration.
Product Attribute | Specifications |
Model Number: | I-644C5TB |
Filter Construction: | Fiberglass |
Working Temperature: | -20 °C -120 °C |
Filtration Rating: | 0.4µm |
Seals Material: | Buna-N |
Application: | Oil Filtration, Aviation |
Maximum Pressure Differential: | 75 psi, 5.2 bar |
Length (inch): | 44 |
Inside Diameter (inch): | 3.5 |
Outside Diameter (inch)： | 6 |
Coalescer Elements Model Number：I-622C5TB、I-644C5TB、I-633C5TB、I-638C5TB、I-656C5TB.
Separator Elements Model Number：S0-623VA5、SO-629VA5、SO-630PV5、SO-630V5、SO-636PV5
