Partner with reliable dust filter cartridge manufacturers for the 8PP-24626-00 replacement. 16.60" lip flange for secure top-load mounting. Get a B2B quote!
Sourcing directly from certified dust filter cartridge manufacturers eliminates supply bottlenecks and ensures precise structural alignment for your extraction systems. The interchangeable replacement for the 8PP-24626-00 unit features a specialized 16.60" lip flange, engineered for secure, leak-proof top-load installation. Packing 78 sq.ft of active media into a compact 20-inch round profile, it prevents particulate bypass in heavy industrial operations, offering facility managers a highly dependable and maintenance-friendly air separation solution.
16.60" Lip Flange Mounting: Designed specifically for top-loading baghouses, the integrated heavy-duty flange allows the cartridge to hang securely from the tube sheet, utilizing gravity and pressure to maintain an airtight seal without complex hardware.
Closed Bottom Pulse Deflection: The solid closed bottom pan forces the reverse-pulse compressed air to deflect outward horizontally through the pleats, amplifying the kinetic energy needed to dislodge stubborn dust cakes effectively.
Wide 10.50" Internal Core: The generously sized internal diameter drastically lowers the upward velocity of the clean air exiting the cartridge, minimizing internal aerodynamic friction and stabilizing the system's differential pressure.
| Engineering Specification | Measurement & Attribute |
| Equivalent Part Reference | Interchangeable Replacement for 8PP-24626-00 |
| Production Source | dust filter cartridge manufacturers |
| Top Cap Design | Open with a 16.60" Lip Flange |
| Bottom Cap Design | Closed |
| Outer Diameter | 13.84 Inches (approx. 351.5 mm) |
| Inner Diameter | 10.50 Inches (approx. 266.7 mm) |
| Overall Span Length | 20.00 Inches (approx. 508.0 mm) |
| Media Surface Area | Approx. 78 Square Feet |
| Cartridge Geometry | Round / Cylindrical |
| Intended Operation | Industrial Dry Particulate Extraction |
Metallurgy Facilities:
Installed in the exhaust systems of ore crushers and sintering plants, effectively isolating abrasive mineral dust and preventing hazardous atmospheric emissions.
Chemical Processing:
Operates safely in bulk powder mixing stations, where the top-load design ensures workers can replace contaminated cartridges from the clean-air side without entering the dirty hopper.
Water Treatment:
Vents the silos used for storing dry flocculants, lime, or activated carbon, securing the pneumatic transfer process against massive particulate blowouts.
HONOR
ISO 14001
ISO 9001
CE
SGS
Patent
Bypassing intermediaries to work with professional dust filter cartridge manufacturers guarantees uncompromising accountability. Ayater enforces strict quality checkpoints in our ISO-driven production lines. Before any 8PP-24626-00 replacement is exported, the 16.60" flange undergoes precise caliper verification to ensure perfect seating on OEM tube sheets, eliminating bypass risks for global B2B operators.
A metallurgy plant faced excessively high labor costs and worker safety concerns during filter replacements in their raw material silos. Their previous bottom-load filters required technicians to enter the confined, dirty hopper. By engaging Ayater as their direct dust filter cartridge manufacturers, they upgraded to the 8PP-42626-00 top-load equivalent. The 16.60" lip flange allowed the maintenance crew to drop the filters in directly from the clean-air plenum. This engineering shift cut maintenance downtime by 65% and drastically improved occupational safety standards.
Tubesheet Sealing Dynamics of Lip-Flange Cartridges
In industrial baghouses, the "tube sheet" is the thick metal plate that completely separates the dirty air zone from the clean air plenum. The integrity of the seal between the filter and this sheet is critical. Traditional cylindrical filters use complex yokes and tie-rods to pull the filter up against the sheet.
The 8PP-24626-00 model employs a highly efficient "Lip Flange" top-load mechanism. The 16.60" flange diameter is wider than the extraction hole. When the cartridge is dropped into the hole from above, the flange rests directly on top of the tube sheet. Gravity provides the initial seating. When the exhaust fan activates, the negative pressure within the dirty zone forcefully pulls the cartridge downward, compressing the flange gasket against the metal sheet. This creates a self-energizing, airtight seal. This design eliminates the need for internal mounting hardware, simplifying baghouse internals and dramatically reducing the time required for filter change-outs.
As recognized dust filter cartridge manufacturers, Ayater operates highly digitized production facilities focused strictly on B2B industrial air and liquid separation. We integrate automated metal stamping for precision flanges, advanced media pleating, and robotic polyurethane dispensing. Our core mission is to empower global processing industries with robust, direct-from-factory filtration technologies that ensure strict emission compliance and operational efficiency safely.
| P191280 | P191281 | P191295 |
| P191310 | P191321 | P191322 |
| P191375 | P191442 | P191444 |
| P191463 | P191469 | P191479 |
| P191496 | P191521 | P191522 |
| P191523 | P191524 | P191525 |
| P191526 | P191527 | P191528 |
| P191529 | P191531 | P191536 |
If you want specific information about other models, please contact us directly!
