Factory supply pleated dust collector filter cartridge customized P191536 replacement. 223 sq.ft. open-end design for pulse-jet systems. Interchangeable with industry-standard 8.38"x12.74"x26" cartridges. Durable media, competitive pricing, rapid shipping.
This replacement for P191536 offers 223 sq. ft. of pleated filtration media in an open-end configuration for reverse-pulse dust collection systems. The 12.74" OD × 8.38" ID × 26" L dimensions ensure direct interchangeability with existing filter housings. Designed as a factory supply pleated dust collector filter cartridge customized for high-airflow applications, this element prioritizes low initial resistance and stable differential pressure progression throughout its service life.
Seamless Retrofit Compatibility
Precision-engineered dimensions (8.38" ID × 12.74" OD × 26" L) ensure drop-in replacement capability for existing dust collector housings without modification.
Open-End Configuration Versatility
The open-top and open-bottom design facilitates efficient reverse-pulse cleaning and simplifies installation in both top-load and bottom-load collector systems.
| Parameter | Specification |
|---|---|
| Part Number | Replacement for P191536 |
| Outside Diameter | 12.74" (323.6 mm) |
| Inside Diameter | 8.38" (212.9 mm) |
| Length | 26.00" (660.4 mm) |
| Top | Open |
| Bottom | Open |
| Shape | Round |
| Filter Media Area | Approx. 223 sq. ft. |
Coal handling and pulverizing operations generate significant respirable dust loads. The replacement for P191536 cartridge provides reliable filtration for material handling dust collectors, bin vents, and pneumatic conveying systems, protecting downstream equipment and maintaining workplace air quality.
Chemical dryers, reactors, and material transfer points often require high-efficiency dust collection. Polyester media with optional PTFE membrane construction offers broad chemical resistance and surface-loading capability for challenging applications involving pigments, plastics, and catalysts.
SGS
CE
ISO 9001
ISO 14001
The filtration performance of pleated cartridges depends on media selection and pleat geometry. PTFE membrane-coated media achieves filtration efficiency of 99.8% for submicron particulates in static tests. Optimized pleat height and pitch reduce pressure drop while maintaining capture efficiency. The open-top/open-bottom configuration supports uniform pulse-jet cleaning energy distribution, reduces re-entrainment, and extends service life.
