Features 130×95×65mm miniaturized dimensions, 2.2kg lightweight design, and multi-angle installation, perfect for space-constrained equipment and tight hydraulic compartments.
The Ayater UH-209 adopts a streamlined housing structure and integrated filter element design, reducing overall dimensions by 25% (130×95×65mm) and weight by 22% (2.2kg aluminum version) compared to standard models. The compact pleated media (0.6-0.9 m² filtration area) maintains high flow rate while minimizing space occupation, fitting into 10L+ small hydraulic tanks.
Equipped with a 360° rotatable port (1.5-inch BSPP/SAE 16) and universal mounting bracket, it supports vertical, horizontal, and inverted installation. The bracket's adjustable sliding design (50-100mm center distance) adapts to irregular compartment layouts, reducing installation space requirements by 30%.
Despite its compact design, it retains 1μm-25μm configurable precision, βₓ(c)≥2000 (ISO 16232-10), and ≤0.25 bar initial pressure drop. The integrated ΔP monitoring (mechanical indicator) saves additional space, ensuring no performance trade-off for size optimization.
| Performance/Design Indicator | Specification |
|---|---|
| Filtration Precision | 1μm, 3μm, 5μm, 10μm, 25μm (configurable) |
| Filtration Efficiency | βₓ(c)≥2000 (ISO 16232-10), ≥99.5% for target particles |
| Max Working Pressure | 350 bar (5075 psi), SAE J1926-1 compliant |
| Operating Temperature | -20℃~100℃; -15℃~150℃ (with Viton seals) |
| Flow Rate Capacity | Up to 150 L/min (39.6 US gpm), optional 180 L/min |
| Overall Dimensions (L×W×H) | 130×95×65mm (aluminum) / 135×100×70mm (cast iron) |
| Net Weight | 2.2kg (aluminum) / 3.8kg (cast iron) |
| Filtration Area | 0.6-0.9 m² (compact pleated media) |
| Installation Type | Vertical/horizontal/inverted, 360° rotatable port |
| Mounting Bracket | Adjustable sliding design, 50-100mm center distance |
| Housing Material | 6061-T6 aluminum alloy / GG25 cast iron (thin-wall optimized) |
| Seal Material | NBR (standard) / Viton (optional) |
| Protection Rating | IP65 (IEC 60529) |
| ΔP Monitoring | Integrated mechanical indicator (1.0-1.5 bar adjustable) |
| Port Size | 1.5-inch BSPP / SAE 16 (rotatable) |
| Compatibility with Hydraulic Tanks | Suitable for ≥10L small tanks |
| Warranty | 5 years (housing) / 1 year (cartridge) |
Perfect for compact construction machinery (mini-excavators), medical equipment (hydraulic lifts), and aerospace ground support tools. The miniaturized design fits into tight engine compartments, while multi-angle installation solves layout challenges in custom hydraulic systems. The lightweight feature reduces equipment overall weight, enhancing energy efficiency for mobile devices.
