Integrates IoT connectivity, remote ΔP tracking, and cloud data synchronization, enabling smart maintenance and real-time system oversight for modern industrial setups.
Equipped with a built-in LoRa/WiFi IoT module (compatible with MQTT/HTTP protocols), the UH-209 transmits real-time differential pressure, temperature, and filter status data to Ayater's cloud platform or third-party SCADA systems. Users can monitor equipment performance remotely via mobile/desktop apps, set custom alert thresholds, and receive instant notifications for filter clogging or abnormal pressure spikes-reducing on-site inspection frequency by 60%.
Key keywords: IoT-enabled hydraulic filter, remote differential pressure monitoring, cloud-connected filter system, smart industrial filtration
The filter's integrated sensors log operational data (flow rate, pressure changes, run time) for up to 2 years, enabling predictive maintenance. Ayater's cloud algorithm analyzes data to generate personalized cartridge replacement recommendations, avoiding premature or delayed maintenance. The system supports batch monitoring of up to 100 UH-209 units, ideal for large-scale industrial facilities with distributed hydraulic systems.
Key keywords: predictive hydraulic maintenance, data-logging filter sensor, batch filter monitoring system, smart maintenance algorithm
Designed with standard industrial communication protocols (Modbus RTU, OPC UA), the UH-209 integrates seamlessly with existing factory automation systems. Its 4-20mA analog output and digital communication ports support two-way data exchange, allowing remote adjustment of ΔP alert thresholds and synchronization of filtration data with enterprise resource planning (ERP) software for holistic operational management.
Key keywords: industrial automation compatible filter, OPC UA hydraulic filter, two-way data exchange filter, ERP-integrated filtration system
| Smart/Technical Indicator | Specification |
|---|---|
| Filtration Precision | 1μm, 3μm, 5μm, 10μm, 25μm (configurable) |
| Filtration Efficiency | βₓ(c)≥2000 (ISO 16232-10), ≥99.5% for target particles |
| Max Working Pressure | 350 bar (5075 psi), SAE J1926-1 compliant |
| Operating Temperature | -20℃~100℃; -15℃~150℃ (with Viton seals) |
| Flow Rate Capacity | Up to 180 L/min (47.5 US gpm), optional 200 L/min |
| IoT Communication Protocols | LoRa, WiFi (802.11 b/g/n), MQTT, HTTP, Modbus RTU, OPC UA |
| Remote Monitoring Range | Up to 5km (LoRa) / Unlimited (WiFi/cloud) |
| Data Logging Capacity | 2 years (1-minute sampling interval) |
| Batch Monitoring Support | Up to 100 units per cloud dashboard |
| Alert Notification Channels | Mobile app, email, SMS, SCADA system |
| ΔP Monitoring Accuracy | ±0.01 bar, max measurable ΔP: 5.0 bar |
| Sensor Types | Differential pressure, temperature, flow rate |
| Housing Material | 6061-T6 aluminum alloy / GG25 cast iron |
| Seal Material | NBR (standard) / Viton (optional) |
| Filtration Area | 0.8-1.2 m² (varies by precision) |
| Protection Rating | IP65 (IEC 60529) |
| Power Supply for IoT Module | DC 9-36V (shared with filter power) |
| Net Weight | 3.0kg (aluminum + IoT module) / 4.7kg (cast iron + IoT module) |
| Warranty | 5 years (housing) / 1 year (cartridge/IoT module) |
The UH-209's IoT integration eliminates manual data logging and on-site inspections, saving 120+ labor hours annually for medium-sized facilities. Real-time alerts reduce unplanned downtime by 35% by addressing filter issues before they impact hydraulic systems. The cloud dashboard provides visual data analytics (trend charts, performance reports), enabling data-driven decisions to optimize filtration efficiency and extend system lifespan. Ayater's technical team offers 24/7 remote support for IoT setup and troubleshooting, ensuring seamless smart integration.
