Ayater UR699 High-Pressure Filter

Ayater UR699 high-pressure filter delivers 3μm ultra-precise filtration, supports 42MPa working pressure, ensures easy maintenance and stable performance for industrial hydraulic systems.

Ayater UR699 High-Pressure Filter

Product Introduction





product-1007-646

As a professional filtration solutions provider, Ayater presents the UR699 High-Pressure Filter-an engineered filtration system tailored for medium to heavy-duty hydraulic systems and high-pressure lubrication circuits. In high-pressure industrial environments, contaminant buildup poses severe risks to hydraulic components; the Ayater UR699 filter addresses this critical issue by integrating advanced filtration technology with a robust structural design. It effectively intercepts tiny abrasive particles, thereby extending the service life of piston pumps, valves, cylinders, and other key hydraulic components, while ensuring the stable operation of the entire hydraulic system.

The Ayater UR699 filter features a user-centric maintenance design that simplifies operational workflows. Its tool-free quick-release locking structure allows UR699 filter element replacement to be completed in just 2 minutes, drastically reducing equipment downtime and labor costs. For safe maintenance, users should first cut off the power supply and relieve system pressure before replacing the element-a standard operating procedure that ensures operator safety and system integrity. Additionally, the filter's optimized internal flow channel design minimizes pressure loss, maintaining smooth oil circulation without compromising system efficiency. It is compatible with ISO VG 32-100 hydraulic oils, anti-wear hydraulic fluids, and synthetic hydraulic oils, providing broad adaptability for diverse industrial applications.

product-538-351



Technical Specifications

Specification

Details

Model Series

Ayater UR699 High-Pressure Filter (UR699 filter)

Operating Pressure

Max 42MPa (UR699 high-pressure hydraulic filter core parameter)

Maximum Flow Rate

500-1200 L/min

Filtration Precision Options

3μm, 5μm, 10μm (Ayater UR699 3μm ultra-precise filter element)

Filtration Efficiency

≥99.5% (β3, β5, β10 ≥200, per ISO16889-99)

Compatible Medium

Hydraulic Oil (ISO VG 32-100), Anti-wear Hydraulic Fluid, Synthetic Hydraulic Oil

Connection Type

Flange Connection (ASME B16.5), Threaded Connection (NPT 3"-5")

Housing Material

High-strength Forged Steel (45#), Optional 304/316 Stainless Steel

Bypass Valve Set Pressure

45±2MPa

Differential Pressure Indicator

Standard (0.6MPa trigger pressure), Optional Electronic Alarm & IoT Monitoring

Replacement Element Part No.

Ayater UR699-EL Series (for UR699 filter element replacement)

Operating Temperature Range

-25℃ to +135℃

Dirt-Holding Capacity

≥220g (for 3μm element)

Seal Material

Viton (High Temperature & Oil Resistant, Low Compression Set)

Pressure Drop (at Rated Flow)

Initial ≤0.08MPa, Max ≤0.6MPa

Weight (Without Element)

48±3kg

Quality Certification

ISO9001, CE Certified

Pressure Drop Informationproduct-597-427

1. Superior High-Pressure Bearing Capacity: With a maximum operating pressure of 42MPa and a high-strength forged steel housing, the UR699 filter achieves excellent structural integrity. It undergoes strict pressure burst testing to ensure no leakage or deformation under long-term high-load operation, outperforming industry peers in heavy-duty high-pressure hydraulic system adaptation.



2. Low Energy Consumption Design: Optimized internal flow channel structure minimizes pressure loss, with initial pressure drop ≤0.08MPa, ensuring smooth oil circulation and reducing system energy consumption.





More models





Xinxiang Saya Filters Co.,Ltd is specialized in manufacture of filter element ,filter equipment,and environment system . Located in Xinxiang City-the center of Filtration in China.ayater has superior R & D team, professional technical team,experienced overseas sales team and perfect after-sales service system.We Lefilter people will try our best to satisfy customers' requirements.The develop philosophy of AYATER is "To purify environment,To serve society,To manage faithfully and To oyrsye excellence"!What's more,there're advanced production line,test machine and R & D department.They also obtained certification like ISO9001, IQNet & CQM,SGS,CNEX etc.



UR699CA32AN20ZA

UR699CC32AN20ZA

UR699CD32AN20ZA

UR699CF32AN20ZA

UR699CA32AN40ZA

UR699CC32AN40ZA

UR699CD32AN40ZA

UR699CF32AN40ZA

UR699CD40AN20ZA

UR699CF40AN20ZA

UR699CD40AN40ZA

UR699CF40AN40ZA

UR699CF48AN40ZA

UR699CA32AN20ZG

UR699CC32AN20ZG

UR699CD32AN20ZG

UR699CF32AN20ZG

UR699CA32AN40ZG

UR699CC32AN40ZG

CA3220Z

CA3240Z

CA3220Z

CC3240Z



UR699CF32AN20ZN

UR699CA32AN40ZN

UR699CC32AN40ZN

UR699CD32AN40ZN

UR699CF32AN40ZN

UR699CD40AN20ZN

UR699CF40AN20ZN

UR699CD40AN40ZN

UR699CF40AN40ZN

UR699CF48AN40ZN

UR699CD32AN40ZG

UR699CF32AN40ZG

UR699CD40AN20ZG

UR699CF40AN20ZG

UR699CD40AN40ZG

UR699CF40AN40ZG

UR699CF48AN40ZG

UR699CA32AN20ZN

UR699CC32AN20ZN

UR699CD32AN20ZN

CD4020Z

CD4040Z

CF4020Z

CF4040Z
