PE Filter Bags

Products Description PE filter bags are primarily made of polyethylene. They offer a diverse range of filtration accuracies, precisely capturing impurities from as small as 0.5-200μm with an impressive removal efficiency of over 90%. Thanks to the material's properties, they have...

Send Inquiry→

Products Description

PE filter bags are primarily made of polyethylene. They offer a diverse range of filtration accuracies, precisely capturing impurities from as small as 0.5-200μm with an impressive removal efficiency of over 90%. Thanks to the material's properties, they have excellent acid and alkali resistance, enabling them to withstand the corrosion of common chemical substances. In terms of temperature adaptability, they can operate continuously and stably in an environment of 135°C, with a maximum working temperature of 150°C. This makes them suitable for meeting the filtration requirements of different industries.

Product Details

1. PE material, soft and odorless

Fine filtration accuracy and high interception rate.

2. 304 stainless steel ring

Withstand higher temperatures, not easy to break.

3. Plastic inner/outer ring, corrosion-resistant

PP resin injection molding, smooth and burr-free.

4. Tight sewing

Ensure the filter bag can achieve better filtration protection.

Filter Bag Ring

filter bag ring

Product Parameters

Liquid pp filter bag

Product	PE filter bags
Features	Corrosion resistance, heat resistance and stability
Precision	0.5-200μm
Nominal Size	01: Ø180 x 430 mm 02: Ø180 x 810 mm 03: Ø100 x 230 mm 04: Ø100 x 380 mm
Filter area	01: 0.24 m² 02: 0.48 m² 03: 0.08 m² 04: 0.16 m²
Maximum Flow	01:20 m³/h 02:40 m³/h 03:6 m³/h 04:12 m³/h
Temperature	150°C (Max.)
Pressure Difference	2.5 bar (Max.)
Replacement Pressure	0.8 - 1.5 bar
Sealing Ring	Galvanized steel,stainless steel,polyester rope,etc.

Material Selection

FILTER BAGS

Application

PE filter bags can be used in such fields:

Food and beverages
Pharmaceuticals
Industrial wastewater treatment
Pure water preparation for electronics factories

Daily Cleaning

Physical Cleaning
Regularly use compressed air back - blow or reverse flushing with clean water to remove the accumulated impurities on the surface and inside of the filter bag. During the operation, the air pressure should be controlled within the range of 0.4 - 0.6MPa to avoid damaging the filter bag.
Chemical Cleaning
When the medium filtered by the filter bag contains oil stains or chemical pollutants, a specialized neutral degreaser can be selected. Dilute it according to a certain proportion, and then soak the filter bag in it for 1 - 2 hours to promote the dissolution of oil stains.
