The pleated high flow filter cartridge 740B40PP010D1 can meet your water treatment filtration needs. Providing high flow rates, it can remove a wide range of contaminants, including sediment, rust, and other impurities. And this filter element is very durable and can provide stable filtration...

![]()
The pleated high flow filter cartridge 740B40PP010D1 can meet your water treatment filtration needs. Providing high flow rates, it can remove a wide range of contaminants, including sediment, rust, and other impurities. And this filter element is very durable and can provide stable filtration results under challenging conditions.
![]()
|
Model |
740B40PP010D1 |
|
Filter type |
Pleated high flow filter cartridge |
|
Overall length |
1016 mm |
|
Overall diameter |
165 mm |
|
Component and assembly materials |
Polypropylene |
|
O-ring material |
Nitrile |
|
Maximum operating temperature |
160 ℉ |
|
Micron rating |
10μm |
|
Flow rate |
18 m³/hr |
![]()

![]()
1.The pleated high flow filter cartridge 740B40PP010D1 is very durable, and the combination of the support frame and filter media enables it to have stable performance and efficiency even in challenging conditions.
2. The large diameter and pleated design of the filter element can increase the filtration area, thereby increasing the dirt holding capacity.
3. The unique end cap design is light in weight and easy to move and install.
![]()

![]()
|
70020310622 |
70020310671 |
70020310689 |
|
70020310697 |
70070226140 |
740B40PP010D1 |
|
740B40PP005D1 |
740B40PP002D1 |
740B40PP001D1 |
|
740B30PP005D1 |
740B30PP002D1 |
740B40PP015D1 |
|
There are many models produced, only part of the display is displayed, there are other models or customized needs can contact us. |
||
![]()
