Natural Gas Amine Filter

The natural gas amine filter is engineered to protect amine-based gas sweetening units by removing entrained solids, aerosols, and liquid droplets from rich and lean amine solutions.

Send Inquiry→

Products Description

The natural gas amine filter is engineered to protect amine-based gas sweetening units by removing entrained solids, aerosols, and liquid droplets from rich and lean amine solutions. Designed for reliability in high-pressure, high-temperature environments, this filter extends the service life of downstream equipment-absorption towers, heat exchangers, and regeneration columns-while maximizing amine purity and minimizing corrosion risks.

Working Principle

Our natural gas amine filters employ sophisticated depth filtration and surface capture mechanisms:

Outer Layer (Pre-Filtration): High-capacity synthetic media traps large particulates (e.g., rust scale, pipe debris > 10-20 microns) and agglomerates, protecting the finer inner layers and maximizing dirt holding capacity.
Mid Layer (Fine Particulate Removal): Tightly controlled glass fiber or synthetic microfibers efficiently capture fine particles down to the rated absolute micron level (e.g., 1 micron, 5 micron), removing catalyst fines, carbon fines, and smaller solids.
Inner Core/Adsorptive Layer (Optional/HSS Mitigation): A specialized activated carbon or resin-impregnated core (available in select models) targets soluble degradation products, organic acids, and trace hydrocarbons – precursors to Heat Stable Salts (HSS) and foaming. This is key for extending amine life and reducing reclamation costs.

Technical Parameters

Parameter	Specification
Filtration efficiency	>99.9% @ nominal absolute precision (e.g. 1µm, 5µm, 10µm) Beta ratio (βₓ) ≥ 1000 (for nominal precision).
Media compatibility	MEA, DEA, MDEA, DGA, Sulfinol, water, ethylene glycol, etc.
Operating temperature	-29°C to 121°C. High temperature models are available on request.
Recommended replacement differential pressure	30-35 psid (2.0-2.4 bar).
Flow Adaptation	For 10", 20", 30", 40" housings (flow optimized design).
FILTER MATERIAL	High purity glass fiber, synthetic polymers (PP polypropylene, PES polyethersulfone), activated carbon/resin composite layer.
Skeleton/Support	Polypropylene (PP) or 316L stainless steel.
End caps	Polypropylene (PP) or 316L stainless steel. Seals: Buna-N, EPDM, Viton O-rings.

Key features

Superior Contaminant Removal

Absolute rated filtration targets both particulates and soluble organics/HSS precursors (with carbon core option).

Extended Service Life

Optimized media structure provides 30-50% higher dirt holding capacity than standard cartridges, reducing change-out frequency and labor costs.

Enhanced Process Reliability

Protects critical assets (pumps, control valves, lean/rich exchangers, absorber/stripper internals) from damage and plugging.

Leak-Free Integrity

Precision-molded end caps with bonded seals ensure reliable performance under pressure.

Customer Cases

1. Case Study: North American Gas Processing Plant Replacing standard 5µm cartridges with our 5µm + Activated Carbon Core design reduced foaming incidents by 85% and extended amine reclaimer run time by 40%, saving over $120,000 annually in amine make-up and reclaimer energy costs.

2. Case Study: Middle East LNG Facility

Implementing our high-flow 10µm absolute cartridges on lean amine service protected critical control valves from erosion. Valve service life increased by 18 months, eliminating unplanned shutdowns and saving $250,000 in valve replacements and lost production.

3. Case Study: Asian Petrochemical Complex

Persistent lean amine pump seal failures were traced to fine carbon fines. Installing our 3µm absolute glass fiber cartridges eliminated the fines, extending seal life 5-fold and reducing pump maintenance costs by 60%.

FAQ

Q: Can this filter handle rich and lean amine streams?

A: Yes, our cartridges are chemically compatible with both rich and lean amine service.

Q: What's the difference between pleated and depth-type filters in amine service?

A: Pleated filters offer higher surface area and lower initial pressure drop, while depth filters have higher dirt-holding for high-solids applications.

Q: Do you offer housings for these filters?

A: Yes, compatible single and multi-round housings in carbon steel, stainless steel, or duplex steel are available.
