Products Description Polypropylene pleated cartridges provide high-flow, depth filtration for corrosive chemicals, solvents, and ultrapure fluids. Featuring pure PP media in an optimized pleat design, they capture sub-micron particles while resisting acids, bases, and solvents up to 80°C....
Polypropylene pleated cartridges provide high-flow, depth filtration for corrosive chemicals, solvents, and ultrapure fluids. Featuring pure PP media in an optimized pleat design, they capture sub-micron particles while resisting acids, bases, and solvents up to 80°C. Engineered for extended service life even in aggressive process streams like semiconductor etchants or pharmaceutical CIP solutions.
| Parameter | Specification |
| Material | 100% Polypropylene (PP) |
| Pore Sizes | 0.2, 0.5, 1, 5, 10, 20, 50µm |
| Nominal Lengths | 9.75" - 40" |
| Max. Operating Temp | 80°C (176°F) |
| Max. Differential Pressure | 5.2 bar (75 psi) @ 21°C |
| pH Compatibility | 1–14 |
| End Caps | Polypropylene, dual open-end (DOE) or single open-end (SOE) |
| Seals | Silicone, EPDM, or Viton options |
| Standards | FDA, USP Class VI |
✓ Deep-Pleat Design → Maximizes surface area for higher flow rates and longer filter life.
✓ 100% Pure Polypropylene Media → Exceptional chemical compatibility; no extractables or leachables.
✓ Gradient Density Structure → Traps particles throughout depth, not just surface (higher dirt load).
✓ Thermally Bonded, No Adhesives → Eliminates glue degradation risk; ensures uncompromised purity.
✓ Broad Pore Size Range (0.2–50µm) → Precise particle retention for diverse applications.
Polypropylene pleated cartridges are widely used in:
 |
 |
 |
 |
Example: MPN5-10S1E
| MPN | 5 | 10 | S1 | E |
| Product Code | Micron | Length | End Cap Configuration | Gasket/O-ring |
| MPN |
0.2 0.5 1 3 5 10 25 50 |
9.75 inches 10 inches 20 inches 30 inches 40 inches |
S1 = DOE S3 = 222 w/ Fin End S4 = 222 w/ Flat End S5 = 226 w/Fin End S6 = 226 w/ Flat End S7 = Internal O-ring with Recessed Plug S9 = Internal O-ring on both ends |
B = Buna N E = EPDM S = Silicone V = Viton T = Teflon Encapsulated Viton (0-ring only) |
