FTS-336-0-10 Coalescing Filter Element is a robust 10-micron cartridge for reliable liquid particulate filtration in Oil & Gas applications, compatible with lube oils, amines, and glycols.
The FTS-336-0-10 is a robust 10-micron coalescing filter element, engineered to protect critical equipment by removing contaminants from lube oils, amines, glycols, and other industrial fluids. Its classic "sock" construction provides a cost-effective and proven solution for numerous industrial applications.
 |
 |
 |
 |
| Parameter | Value |
| Model Number | FTS-336-0-10 |
| Product Type | Coalescing filter element |
| Micron Rating (nominal) | 10 µm |
| Length | 36.6 inches |
| Outside Diameter | 3 inches |
| Inside Diameter | 1.6 inches |
| Filter Material | Cotton/Synthetic/Excelsior Blend |
| Filter Construction | Rolled Depth |
| Maximum Operating Temperature | 115℃ |
| Maximum Pressure Differential | 7.6 bar |
| Recommended Changeout ΔP | 20 PSID |
| Core Material | Tin-Plated Steel |
| End Cap Configuration | DOE- w/ internal CS compression spring |
| Flow Direction | Outside-to-inside |
| pH Range | 3-9 |
| Application | Liquid Particulate Filtration |
| Industry | Oil & Gas |
✅ Rolled-depth sock construction (cotton/synthetic/excelsior blend) for progressive, high-capacity particulate capture.
✅ DOE end-cap configuration with internal CS compression spring for positive compression sealing in compatible vessels.
✅ 10 micron nominal rating with outside-to-inside flow direction suitable for lube oils, fuels and common process liquids.
✅ Robust internal tin-plated steel core supporting long open-flow life and structural stability.
This FTS-336-0-10 coalescing filter element is engineered for use in the following areas:
Primary Industries: Oil & Gas
Target Fluids:
| FT- 318-O-5 | FT- 436-O-5 | FTS-336-C- 50 | FTS-336-C- 20 |
|
FTS-318-O- 10 |
FTS-324-C- 10 | FTS-336-C- 75 | FT- 336-C-2-5 |
| FTS-318-C- 75 | FTS-336-C- 25 | FTS-336-C-100 | FTS-318-C- 25 |
CE
