Specifications
| Material | PP, Fiberglass, polyester |
| Precision | 10μm |
| Outer-diameter | 6inch |
| Length | 20 inch,40 inch,60 inch |
| Inside core/End caps | PP |
| Flow rate | 1300L/min |
| Gasket material | NBR |
| Max water flow rate | 1300LPM |
| Filter change pressure drop | 2.4bar,20ºC |
| Size | Customized |
| Filter flow | 110m3/H |
The whole structure of polypropylene, end cover, housing, and center pole adopts polypropylene material; It adopts the hot-melt welding process, PP and PP melt bonding, without any binder.
It has a wide range of chemical compatibility, and also has a series of pore size and form a variety of interface. Material: Pleated filter, Support layer, End-cover, Inside & Outside cylinder are polypropylene.
Welding: It adopts unique hot melting methods, with no glue, and no foreign body falling off.
Typical use: Pharmaceutical, Food, Chemical, Electronics, Environmental protection, etc.
Microporous membrane pleated filter cartridge main features: High interception rate, high liquidity, low-pressure differential, and a wide range of chemical compatibility;
The production process adopts unique hot melting process technology, no any adhesive, and no foreign body release. It can meet the food, beverage, beer, chemical, pharmaceutical, and other industries' production requirements.
Applications
Pre-filtration or an RO system, DI water
Solvents, selected acids&lyes, chemical industry
Semiconductor, Electronic industry ultrapure water system
FOOD and beverage, drinking water treatment
High Flow filter elements are designed for high particle removal efficiency of fine particulates from water applications.
