Ayater filter element Design Ayater filter elements are made from specially formulated filter media selected to provide the most effective combination of fluid particle separation, fluid compatibility, and structural properties. The media is pleated with controlled-radius pleats, which maximize...
Ayater filter element Design
Ayater filter elements are made from specially formulated filter media selected to provide the most effective combination of fluid particle separation, fluid compatibility, and structural properties. The media is pleated with controlled-radius pleats, which maximize effective filtration area and dirt-holding capacity, and resists bunching, distortion, and rupture. Sharply creased pleats overstress fibers, causing cracks and bypassing. Ayater's manufacturing process forms a larger radius pleat on the outside and a smaller one on the inside. This causes the pleat geometry to assume an elliptical shape which stiffens the pleat pack and acts as a pleat separator to provide uniform pleat spacing. This feature permits lower pressure drops and larger dirt capacities over those of sharply pleated elements.
Ayater hyaulic filter structure
Hilco PL518-10-C Specification
OEM Part Number | PL518-10-C |
Efficiency | 10 Micron |
Collapse Rating | 75 |
Max Temp (F) | 250 |
Adhesive | Plastisol |
By-Pass | None |
End Cap | Corrosion Resistant CS/AL |
Flow Direction | Out/In |
Media Type | Phenolic Impregnated one side |
Recommended Change Out (psid) | 25 |
O.D. | 4.5 |
Length | 18 |
Seal Material & Type | Cork Flat |
Quantity per Carton | 6 |
Weight per Filter (lbs) | 3.0000 |
