Optimize your compact machinery with the Ayater MF Spin On Filter. Featuring a lightweight aluminum head and a quick-change disposable canister, it delivers absolute filtration for low-flow hydraulic circuits. Ensure peak fluid cleanliness and prevent premature wear in space-constrained manufacturing applications with our rapid-maintenance design.
In the highly demanding sector of precision manufacturing, the cleanliness of hydraulic fluid directly dictates the accuracy and lifespan of CNC machining centers and automated lathes. The Ayater MF Spin On Filter is specifically engineered to address the unique challenges of compact, low-flow hydraulic circuits. Operating efficiently at flow rates up to 80 liters per minute, this unit acts as the ultimate barrier against microscopic particulate contamination. By intercepting metallic shavings, dust, and degradation byproducts before they return to the reservoir, the MF Spin On Filter prevents the scoring of sensitive servo valves and the premature degradation of hydraulic pumps, ensuring your production lines maintain absolute dimensional accuracy.
The core of the Ayater MF Spin On Filter is its state-of-the-art inorganic micro-glass filtration media, securely sealed within the disposable steel canister. Unlike traditional cellulose paper elements that swell and degrade over time, our synthetic glass fiber matrix maintains its structural integrity even under continuous fluid shear. This advanced media provides an exceptional beta ratio (ßx(c) > 1000), meaning it captures over 99.9% of targeted contaminants in a single pass. The deep-pleated architecture maximizes the active surface area within a minimal footprint, resulting in a remarkably low initial pressure drop and a significantly higher dirt-holding capacity.
Downtime in a CNC environment is incredibly costly. The Ayater MF Spin On Filter is designed with user-centric, rapid maintenance in mind. Unlike traditional bowl-style filters that require cleaning and expose the system to environmental dirt during element changes, the spin-on design allows technicians to simply unscrew the saturated canister and thread on a new one. This completely eliminates the risk of cross-contamination during servicing. To eliminate guesswork, the aluminum head features a standardized port for a visual or electrical clogging indicator, alerting your maintenance team exactly when the canister reaches its maximum capacity.
| Parameter | Specification Details |
| Max Operating Pressure | 8 bar (116 psi) / Max 12 bar surge |
| Nominal Flow Rate | Up to 80 L/min (21.1 GPM) |
| Filter Head Material | Die-Cast Aluminum Alloy |
| Canister Material | High-Strength Carbon Steel |
| Filtration Rating | 3 µm, 5 µm, 10 µm, 20 µm (Absolute) |
| Bypass Valve Setting | 3 bar (43.5 psi) ± 10% (Integrated in Head) |
| Connection Port | G 3/4" or SAE-12 Threaded |
| Fluid Temperature Range | -20°C to +100°C (-4°F to +212°F) |
| Seal Material | NBR (Standard), FKM (Optional) |
Purchase More Similar Models
Ayater provides a comprehensive suite of compact, quick-change fluid conditioning solutions tailored for the machine tool industry. If your equipment requires different flow capacities or specialized port configurations, please contact us to purchase or inquire about these similar models:
MF Spin On Filter 030 (Up to 30 L/min)
MF Spin On Filter 070 (Up to 70 L/min)
MF Spin On Filter 090 (Up to 90 L/min)
