940734 Hydraulic Filter Element

940734 Hydraulic Filter Element: A high-performance, cost-effective replacement filter designed for reliable water removal in low-pressure hydraulic systems (up to 200 PSI / 10 GPM). Ensure system purity and prevent water-induced damage with this dependable direct-fit solution.

Send Inquiry→

Products Description

The 940734 is a direct-replacement hydraulic filter element built to keep water out of hydraulic oil. It slips in where the original went - no plumbing changes, no surprises. The result: less corrosion, cleaner oil, and fewer unexpected repairs.

Product details

Technical parameters

Parameter	Specification
Part Number	940734
Filter Type	Low-Pressure In-Line Suction / Return / Duplex Filter Element
Height	592.8 mm
Outer Diameter	126 mm
Filter Media	Composite Glass Fiber with Integrated Water Removal Capability
Filtration Rating	10 Microns (Nominal)
Filtration Efficiency	99.5% (Beta Ratio ≥200 at 10 microns)
Seal Material	Buna-N (Nitrile Rubber), offering excellent oil compatibility
Max. Operating Temperature	250°F (121°C)
Element Design	Spirally-Omitted End (SOE) with 45-degree Top Bypass Valve

Key features

✅ Removes free water from hydraulic fluid so pumps, valves and cylinders last longer.
✅ Fits as an OEM-style drop-in replacement - correct size and seal.
✅ Uses industrial-grade media and NBR (nitrile) seals for steady, reliable service.
✅ Simple to swap during routine maintenance - fast changeouts, predictable downtime.

Applications

The 940734 hydraulic filter element is a versatile component trusted across numerous industries to protect hydraulic systems. Typical applications include:

Machine Tools: CNC lathes, milling machines, grinding machines.
Metal Production & Fabrication: Hydraulic presses, shears, rolling mill auxiliary systems.
Mobile Equipment: Lubrication systems, low-pressure circuits on engineering machinery.
Plastic Injection Molding Machines.
Industrial Hydraulic Power Units.
