HCP series filtration principle: 1. Filtration: when passing through the filter medium, solid particles are removed from the fluid; 2. Coalescing: When passing through the multi-layer filter medium of the coalescence filter element, small droplets converge into large droplets; 3. Separation: gravity action, large droplet separation
HCP100 oil purifier filtration principle:
Filtration: As solid particles pass through the filter medium, solid particles are removed from the fluid.
Coalescing: When passing through the multilayer filter media of the coalescing filter element, small droplets converge into large droplets.
Separation: gravity action, separation of large droplets.
Model | HCP50 | HCP100 | HCP150 | HCP200 |
Inlet (male thread) | M64*2" | |||
Outlet (male thread | M52*2" | |||
Motor power（Kw） | 1.5 | 3 | 4 | 6 |
Rated current（A） | 4.5 | 8.2 | 8.8 | 15 |
Medium | low viscosity lubricating oil | |||
Inlet pressure（bar） | -0.4~1.0 | |||
Operating temperature（℃） | 40~70 | |||
Media viscosity（Cst） | ≤46 | |||
Power supply | 380V,50Hz | |||
Form factor（mm） | 1200*750*1560 | 1800*900*1700 | 1960*1050*1760 | |
Weight（Kg） | 350 | 550 | 580 | 850 |
HCP50A38050A-C HCP50A38050A-S HCP50A38050K-C HCP50A38050K-C
HCP100A38050A-C HCP100A38050A-S HCP100A38050K-C HCP100A38050K-C
HCP150A38050A-C HCP150A38050A-S HCP150A38050K-C HCP150A38050K-C
HCP200A38050A-C HCP200A38050A-S HCP200A38050K-C HCP200A38050K-C
