HNP series oil purifier purifies oil by removing water pollutants and gases.
Minimizing water contamination can extend the reliability of systems and the life of system components and fluids.
The HNP006 oil purifier is designed to remove water from oil in low-volume systems or where access to conditioning equipment is limited.
Benefits of HNP006 Oil Purifier：
High-performance water, gas, and particulate removal
Simple automated operation
Extension of fluid life
120V single-phase electric connection
Extended fluid life
Minimized corrosion within systems
Increased equipment reliability
Reduced operating costs
Model | HNP006 | HNP021 | HNP073 | HNP200 |
Weight（Kg） | 75 | 180 | 650 | 1760 |
Form factor（mm） | 695*455*1041 | 1090*620*1040 | 1580*1170*2113 | 2679*1662*3266 |
Inlet (male thread) | G14.5" | G1" | G2" | G4" |
Outlet (male thread） | G1〞 | G1½" | G3" | |
Flow rate（L/min） | 10 | 20 | 70 | 229 |
Total motor power（KW） | 0.67 | 2.25 | 6.4 | 22.7 |
Scope of application of oil | Hydraulic oil, lubricating oil, etc | |||
Maximum viscosity（Cst） | 700 | |||
Temperature range（℃） | 10~70 | |||
Outlet working pressure（Bar） | 10 | 7 | 8 | |
Inlet working pressure（Bar） | 2 | -0.4~0.4 | -0.4~3 | |
Vacuum value（Bar） | -0.7~-0.9 | 0.8 | -0.6~-0.9 | |
![W{6)(O7]TGIND]P6B6VW[K5](https://www.ayaterfilters.com/Content/uploads/2023630831/202306081000308fc275733fb24259a34639ddd773429c.png "W{6)(O7]TGIND]P6B6VW[K5")
