High-flow water filter cartridge is processed by a variety of composite materials through special technology, with hydrophilic characteristics, it can not only filter out mechanical impurities in the medium, but also through demulsification, coalescence, so that the emulsified state of water is separated from the medium, and coalesced into larger water droplets, in order to facilitate further purification of the medium
Ayater high-flow cartridges are made of deep fine polypropylene or glass fiber membrane as filter media, with a large diameter of 6 inches / 152mm, no center rod, unidirectional opening, and specially designed to flow the liquid from the outside to the inside, ensuring that all contaminant particles are trapped outside the cartridge.
Application: RO pre-filtration, seawater desalination pretreatment; power plant condensate filtration; biopharmaceutical industry API, solvent, water filtration, etc.
| OD： | 6" (152mm) |
| Length： | 20"/40"/60" |
| Micron： | 0.1um~100 um |
| Maximum operating temperature： | Pleated/melt-blown pp: 82ºC |
| Pleated glass fiber: 121ºC | |
| Maximum operating differential pressure: | Pleated/melt-blown pp: 3.44bar@82ºC |
| Pleated glass fiber: 3.44bar@121ºC | |
| Suggestion design flow: | 40": ≤15m3/h |
| 60": ≤25m3/h |
RCP045-60EPP RCP045-60NPP RCP100-20EPP RCP100-40EPP RCP100-60EPP RCP200-20EPP
RCP200-40EPP RCP200-60SPP RCP400-20EPP RCP400-40EPP RCP400-60SPP RCP900-40EPP
RCP900-60EPP RSCP010-20EPP RSCP010-40EPP RSCP010-60SPP RSCP030-40EPP RSCP045-20EPP
RSCP030-60EPP RSCP045-40EPP RSCP045-60EPP RSCP045-60NPP RSCP100-20EPP RSCP100-40EPP
RSCP100-60EPP RSCP200-20EPP RSCP200-40EPP RSCP200-60SPP RSCP400-20EPP RSCP400-40EPP
RSCP400-60SPP RSCP900-40EPP RSCP900-60EPP RMG010-20EPP RMG010-40EPP RMG010-60SPP
RMG030-40EPP RMG045-20EPP RMG030-60EPP RMG045-40EPP RMG045-60EPP RMG045-60NPP
