Products Description Amine based filters are designed for use in amine gas treatment units and are intended to remove solid particles and contaminants from amine solutions. Primary Function: Continuous removal of insoluble contaminants (iron sulfide, salts, carbon fines) from lean and rich amine...
Amine based filters are designed for use in amine gas treatment units and are intended to remove solid particles and contaminants from amine solutions.
Classification by Critical Applications
| Type | Target Contaminant | Natural Gas Use Case |
| Coalescing | Hydrocarbon aerosols | Inlet gas scrubbing |
| Particulate | Iron sulfide, carbon | Amine reclaimer protection |
| Activated Carbon | Organic acids, degradation products | Foam prevention in amine contactors |
| Parameter | Specification Range |
| Filter Media | Polypropylene, PTFE, Stainless Steel (316L) |
| Micron Rating Options | 0.5 - 50 µm |
| Operating Temperature | –20 °C to +230 °C (depending on cartridge type) |
| Maximum Operating Pressure | 150 psig (polymeric) – 500 psig (metallic) |
| Amine Compatibility | MEA, DEA, MDEA, DGA, AMP, Sulfuric acid traces |
| Flow Rate per Cartridge | 500–10,000 LPM (dependent on ΔP and micron size) |
| ΔP (Initial/Final) | < 0.2 bar (initial); up to 1.0 bar (max) |
| Housing Connection Styles | 226/Flat 222, SOE (DOE), Double O‐Ring, Flanged |
| End Cap Styles | 2″ Open‐End, Single Open End/Single Closed End |
| Housing Material Options | Carbon steel (coated), 304/316L SS, Duplex SS |
| Typical Cartridge Lengths | 5″, 10″, 20″, 30″, 40″ |
| Recommended Replacement Interval | 3–6 months (depending on loading) |
✅ High Chemical Compatibility:
Resists degradation in contact with acidic gases (H₂S, CO₂) and corrosive amines.
✅ Extended Filter Life:
High dirt-holding capacity reduces replacement frequency and lowers operational cost.
✅ Foaming Control:
Reduces surfactant presence, preventing foaming in the absorber column.
✅ Improved Heat Exchanger Performance:
Minimizes fouling and scaling on heat transfer surfaces.
✅ Modular Design:
Enables quick retrofit into existing amine circuits with minimal modification.
1. Natural Gas Sweetening Units
Filtering rich/lean amine before and after regeneration cycles.
2. Hydrocarbon Refining Units
Desulfurization units (HDS), removing contaminants prior to amine reclaimer.
3. Petrochemical Plants
Protecting process reactors and downstream analyzers from amine impurities.
4. Offshore Gas Processing
Compact skids for FPSO and platform gas treatment.
Q: Will this remove heat-stable salts (HSS) from my lean amine?
A: Yes - our multilayer design targets HSS like formate, acetate, and oxalate causing reboiler scaling.
Q: Compatible with sulfolane-based solvents?
A: Confirm solvent blend - we offer PTFE membrane options for aromatic systems.
Q: Do you offer customized amine based filter lengths or end cap designs?
A: Yes. We manufacture filter cartridge s in non‐standard lengths (50″, 60″) and custom end caps (double o‐ring, flanged) to fit unusual housings. Contact our engineering team with dimensions and operating specs.
