PS-230-S1C-40EV Filter Cartridge

The PS-230-S1C-40EV filter element, with polyester filter media at its core, combines excellent abrasion resistance and chemical stability. Its structure, featuring an outer diameter of 2.5 inches, an inner diameter of 1.0 inch, and a length of 30 inches, along with a filtration accuracy of 40μm, can effectively intercept both large - sized impurities and fine contaminants. The 2.5" cs spring/open - end caps, combined with Viton seals, ensure a tight seal. With an operating temperature of up to 240ºF (116ºC), it is suitable for high - temperature fluid filtration scenarios in industries such as petrochemicals and mechanical manufacturing.

Workshop Scene

Product Features



Product Features of Filter Element PS-230-S1C-40EV,

• The polyester filter media is abrasion - resistant and chemically stable, enabling adaptation to fluid environments with a pH range of 3 - 9.​
• With a filtration efficiency of 99.98% at 40μm, it precisely intercepts contaminants of varying particle sizes.​
• The 2.5" CS spring/open - end cap design provides reliable mechanical support.​
• The Viton fluororubber seal can withstand high temperatures up to 240°F (116°C), effectively preventing media leakage.



Application



The PS-230-S1C-40EV filter cartridge can be used in such fields,

• Semiconductor cleaning solutions
• Pharmaceutical process water
• Heat transfer fluids
• Electroplating baths
