Products Description NMO-150-P04S-50S nylon filter bags are specifically engineered for reliable 150 µm surface filtration. Featuring a dimensionally stable nylon monofilament mesh and galvanized retaining rings, they deliver predictable particle capture, low bypass rates, and quick...
NMO-150-P04S-50S nylon filter bags are specifically engineered for reliable 150 µm surface filtration. Featuring a dimensionally stable nylon monofilament mesh and galvanized retaining rings, they deliver predictable particle capture, low bypass rates, and quick replacement at flow rates up to 12 m³/h.
 |
 |
 |
| Parameter | Specification |
| Model Code | NMO-150-P04S-50S |
| Catalog Number | F5814969 |
| Micron Rating | 150 µm |
| Filter Media | Nylon Monofilament Mesh |
| Bag Size | Size 04 |
| Diameter | 4 inch (100 mm) |
| Length | 15 inch (380 mm) |
| Filter Area | 0.16 m² |
| Max Flow Rate | 12 m³/h |
| Max Operating Temperature | 190 °C |
| Max ΔP | 2.5 bar |
| Construction | Sewn with Anti-Bypass Protection |
| Gasket Type | Zinc-plated steel snap-ring |
✅ Precision 150 µm nominal retention: finer particle capture with consistent pore geometry for reliable surface filtration.
✅ High-capacity flow: 15" length and 0.16 m² area support up to 12 m³/h while maintaining low differential pressure.
✅ Robust thermal & chemical resistance: nylon monofilament maintains shape to 190 °C and withstands aggressive chemistries and 2.5 bar ΔP.
✅ Pressure-activated, low-bypass seal: zinc-plated SENTINEL snap-ring delivers a positive, adaptive bag-to-housing seal.
NMO-150-P04S-50S nylon filter bags are suitable for the following critical filtration requirements:
 |
 |
 |
|
NMO-150-P03S-50S |
NMO-150-P01Z-60L |
NMO-50-P02Z-60L |
|
NMO-150-P01S-60M |
NMO-150-P03Z-50M |
NMO-300-P01Z-60L |
|
NMO-150-P02Z-60L |
NMO-600-P01S-60L |
NMO-1000-P03S-50M |
|
NMO-150-P04Z-50M |
NMO-800-P03S-50M |
NMO-5-P01Z-60L |
