The PP pleated filter element XL20PP002F0A maximizes the useful surface area of the filter element while maintaining an open flow path between the media pleats. With an absolute filtration accuracy of 0.2μm, the efficiency reaches 99.9%. The PP material provides chemical and thermal compatibility, making it applicable in a wide range of fields.
|
Model |
XL20PP002F0A |
|
Length |
50.8cm |
| O.D | 6.65cm |
| Precision | 0.2μm |
|
Media |
100% PP |
|
Cap |
226 O-Ring and Flat |
| Operating Temperature |
175 °F (80 °C)
|
|
Max Reverse Differential
Pressure
|
40 psid @ 77 °F (2.6 bar at 25 °C)
|
100% polypropylene construction.
Pleated filter layer.
Equipment processing.
Finished folded water filter element.
| Code | Length | Filter Media | Rating | End Code | O-ring |
| XL | 10-10" | pp | 002(0.2μm) | B0--226 O-ring&Spear | A-Silicone |
| 19-19.5" | 005(0.5μm) | B1--226 O-ring&Spear | B-Fluorocarbon | ||
| 20-20" | 010(1μm) | B2--226 O-ring&Spear | C-EPR | ||
| 30-30" | 025(2.5μm) | C1--222 O-ring&Spear |
G² – Polyethylene
|
||
| 40-40" | 050(5μm) | D--Double Open End |
K² – FEP/PFA
|
| XL30PP100B0C | XL29PP005DA | XL30PP010B2C |
| XL30PP100C0A | XL09PP200DC | XL10PP100B0K |
| More details,please contact us. | ||
